General

• Type: Lint 41/H
• Manufacturer: Alstom LHB in Salzgitter (DEU)
• Number offered: 9 trainsets
• Year of manufacture: 2002
• Type of rail vehicle: Diesel-hydraulic two-car trainset
• Location: Hengelo (Ov.), the Netherlands
• Admission: Netherlands
• Description: 9x Lint 41/H DMU trainsets. Powered by 2 diesel-hydraulic power packs per trainset. Maintenance performed by Nedtrain in the Netherlands, according to original documentation. 2 Mio kilometer overhaul performed in 2017 by Shunter. Annual mileage is 160,000 per train set. 1 Mio kilometer overhaul planned in 2025. Train sets are sold including main spare parts: 2x diesel engine, 6x generator, 4x transmission, 5x gearbox with reversing, 7x gearbox without reversing, 7x wheelset axle 1/6, 7x wheelset axle 2/5, 4x wheelset axle 3/4.

Vehicle data

• Length over couplings: 41.890mm
• Wheel diameter min/max: 710mm/770mm
• Number of axles: 6 (B'-2'-B')
• Center to center distance bogie: running bogie 2,700mm / motor bogie 1,900mm
• Total weight empty/loaded: 63.4t / 82.0t
• Maximum axle load: 16t
• Technical maximum speed: 120 km/h
• Braking system: MRP C-pn-P-A-H-Mg (D)
• Engine power: 2x 315kW

Infrastructure compatibility

• Communication functionality: GSM-R
• Boundary profile: EBO-G2 and OPS-NL
• Loading category: C2
• Automatic train influence: ATB-EG and ATB-NG
